性能参数Parameter

 挖掘深度Maximum digging depth

mm

2760

 挖掘高度Maximum digging height

mm

3850

 回转半径Minimum swing radius

mm

2120

 发动机型号 Engine model

新柴

4D27

 发动机功率

KW

36.8

 标准铲斗容量Bucket capacity

m³

0.1

 工作压力 Working pressure

MPa

22

 接地比压 Ground specific pressure

KPa

30

 回转速度Rotary speed

rpm

10

 行走速度Walking speed

km/h

2.5

 履带宽度 Track width

mm

250

 离地间隙Ground clearance

mm

510

 爬坡能力Climbing ability

°

<30

 全车总宽Width

mm

1600

 全车总高Height

mm

2450

 全车总长Length

mm

4320

 整机重量Weight

kg

2780
